KNOW YOUR MACHINE
21 Tie Down Location (2 rear)
23 Control Panel
24 Recovery Tank Cover
25 Recovery Tank Shutoff Float
26 Vacuum Motor Filter Housing
27 Debris Catch Tray
28 Recovery Tank Drain Hose
29 Recovery Hose
30 Squeegee Tilt Adjust Knob
31 Squeegee Mount Thumb Nuts
32 Squeegee Caster Lock Knob
33 Squeegee Assembly
34 Hopper (Cylindrical only)
35 Scrub Deck
36 Solution Filter
37 Solution Shutoff Valve
38 Solution Solenoid Valve (on scrub deck)
23
25
28
31
32
33
21
34
35
37
36
29
30
24
26
27
38
