E
Nilfisk
ALTO
Attix7_ver.1.0_140105
3.8 Removing/fitting belt (all models)
1. Take the cleaner head
with the adapter ring off
the container, and lift the
container out of the base
frame.
2. Mark the position of the
belt on the container (1).
3. Take out the C-coupling
(2) with a long screwdriver
(only cleaners used by fire
brigades).
4. Thread a normal length
of cord (3) or the like (60-
80 cm) through one of the
loops (4) of the tensioning
device, and pull the loop
(4) back over the catch
(6). Detach the second
loop (4) in the same way,
and take off the belt (7).
5. Fit in the reverse order,
making sure the belt (7) is
correctly positioned.
Note:
On cleaners used by fire
brigades, always fit the C-
coupling (2) first as a posi-
tioning aid.
Attix7 3663
1
2
Attix7 3662
3
7
4
4
6
6
☞
