4.7 Removing/fitting hood (Attix 791-2M/B1)
1. Unscrew the cooling air
filter (see 4.6).
2. Unscrew the socket
(see 7.4).
3. Undo the two screws (3)
with an Allen key (5 mm),
and take off the grip.
4. Undo the four screws
(4) of the locking clamps
with a Phillips screwdriver,
and take off the hood.
5. Fit in the reverse order.
4.6 Removing/fitting cooling air filter (Attix 791-2M/B1)
1. Undo the screw (1) with
an Allen key (5 mm), and
take off the cover.
2. Pull off the filter insert
(2) forwards.
3. Undo the four screws
(3) with a Phillips
screwdriver, and take off
the filter case.
4. Fit in the reverse order.
1
Attix7 3612
Attix7 3616
3
3
3
3
2
4
4
4
4
3
3
Attix7 3625
Troubleshooting
r h
T o
ubl
e
s
ootin
g
31/59
