Table B.3: Neptune 4-42
Note: Neptune 4-42 *EU* is also available as X-model.
3. NEPTUNE 4-42
Neptune
4-42
*EU*
Machine protection category IP X5
Current consumption A 10
Voltage V 400
Frequency Hz 50
Connected load kW 5,6
Sound pressure dB (A) 76,5
HP nozzle 0475
Pressure P1 / P1 max. bar 170 / 250
Pressure P2 / P2 max. bar 25 / 32
M ax. recoil force N 43
W ater throughput (max.) l/h 860
W ater throughput (EN 60335-2-79) l/h 800
W ater intake pressure (max.) bar 10
W ater intake temperature (max.) °C 40
Voltage V 400
Frequency Hz 50
Connected load kW 4,5
Motor insulation CL. F
Ingress protection IP 54
RPM U/min 1450
Type NP5 13.20
Plunger ceramic
Plunger diameter mm 18
Plunger stroke mm 12,8
Pump oil SAE 15 W 40
Amount of oil ml 1000
Fuel pressure bar 15 (- 0,5)
Fuel consumption dt = 45 K kg/h 3,9
Exhaust temperature °C 185
CO
2
content (min.)
% 10,5 (+ 0,5)
Soot rating 0 - 1
Efficiency % > 92
W ater content (coil) l 3,5
Heating power kW 70
Length mm 1053
W idth mm 685
Height mm 750
W eight kg 132,5
H igh-pressure hose D N 8 x 10 m
Electrical lead m 5
Fuel tank l 16
Detergent tank l 10
Heat exchanger
Di men-
sions and
weight
Miscella-
neous
NEPTUNE 4
Technical machine dataMo to rPump
Technical data
Neptune 4_EN_Ver.1.0_04/06
5/21
