MACHINE STRUCTURE (Continues)
41
42
59
18
46
47
44
45
52
43
50
53
57
51
49
48
58
54 55
56
S311231A
Recovery water tank cover (open)
Recovery water tank cover gasket
Brush/pad support (engaged)
Recovery water tank compartment
Solution tank fi ller neck
Vacuum grid with automatic shut-off fl oat
Recovery water drain hole
Vacuum system motor
Brush/pad-holder motor
Batteries
Battery connection diagrams
Brush/pad-holder deck
Machine speed adjustment screw
Brush
Pad-holder
Pad
Screw
Brush/pad-holder engagement rotation direction
Cover support rod (engaged)
