909 6313 000(2)2007-06 A SCRUBTEC 343B 9
USER MANUAL
ENGLISH
TECHNICAL DATA
General SCRUBTEC 343B
Machine length with folded handlebar 1,020 mm
Machine width with squeegee 720 mm
Machine width without squeegee 570 mm
Min/max machine height with adjustable handlebar 860 - 1,105 mm
Total machine weight 72 kg
Minimum turning radius 750 mm
Cleaning width 430 mm
Battery compartment size 350x350x260 mm
Central wheel diameter 250 mm
Brush/pad diameter 430 - 432 mm
Wheel on-fl oor pressure 0.36 N/mm
2
Brush/pad pressure on the fl oor 23 kg
Performance SCRUBTEC 343B
Vacuuming 1,055 mmH
2
O
Brush/pad-holder motor speed 135 rpm
Sound pressure level at workstation 70 dB(A)
Vacuum system motor power 300 W
Brush/pad motor power 520 W
Gradeability 2%
Battery voltage 24 V
Standard batteries 2 x 12 V, 50/70 Ah (GEL)
Clean water tank capacity 31 litres
Recovery water tank capacity 30 litres
