2. Permanently installed and connected to a mechanical exhaust air
ventilation system
When the drying cabinet is permanently
connected to the evacuation duct, the
whole room is ventilated by way of the
drying cabinet.
 Fit the sleeve supplied to the hose.
Ax the sleeve and hose to the dryer
top.
The insert is not supplied.
Air intake
The air intake must not be blocked.
1. Insert
2. Hose
3. Sleeve
Moist air out
