TECHNICAL DATA ETS 1700E / 1900E
Capacity: approx. 4,0 kg washing (cotton)
Dewatering capacity: 4/10/17 g/min.
Electrical connections: single-phase 230 V, 50-60 Hz
Motor: 35 W
Heating element: 750/1500 W
Overheating cut-out: Yes
Fan capacity: 180 m³/h
Hanging length: 16 metres
Dimensions: Height: ETS 1700E 1700 mm
ETS 1900E 1900 mm
Depth: 610 mm
Width: 595 mm
Weight: ~54/56 kg
Sound level: maximum 60 dB (A)
ENERGY CONSUMPTION AND DRYING TIME WHEN DRYING SPUN WASHING
Programme Energy consumption Drying time Temp. maximum
kWh/kg washing
AUT 40°C 0.4 approx. 2 h approx. 45°C
AUT 60°C 0.6 approx. 2 h approx. 65°C
MAN 30°C 0.3 (2 h 30 min) manual setting 15 min - 6 h approx. 35°C
MAN 40°C 0.4 (2 h 30 min) manual setting 15 min - 4 h approx. 45°C
MAN 60°C 0.6 (2 h 30 min) manual setting 15 min - 4 h approx. 65°C
MAN -- °C 0.08 (8 h) manual setting 15 min - 12 h only fan
*) Given values may vary depending on:
- spin speed
- temperature and air humidity in the room
- air circulation in the room (supply air, exhaust air)
*)
MANUFACTORING
STANDARD
See the identifica-
tion plate
ELECTRICAL
DIAGRAM
The electrical circuit
diagram can be or-
dered from the ma-
nufacturer. Address
- see page 2.
