Usermanual NIMOS Micro-Trac Page 13
5 Implements
Before (de)coupling: stop the machine and disengage all hydraulic functions (switches 22 and 50 to 57).
Engage the parking brake. Read the manual of the implement carefully.
5.1 Coupling
¾Check if coupled implements don't endanger the stability of the machine. Here you will find the maximum
weights and dimensions:
front lift rear lift
distance centre of gravity to centre front axle: 1000 mm. rear axle: 850 mm.
max. weight of implement 150 kg. 200 kg.
¾ Extra implement pump supply’s 21l.min at 3600 Rpm with 175 bar of pressure
always check the required power of the implement
¾ Bolt all pins and strips after coupling implements.
¾ Clean dirty quick couplings before coupling.
¾ Couple the lift cylinder to the Single Acting quick coupling (H).
¾ Couple the swivel cylinder to the Double Acting quick coupling (DW / two couplings).
¾ Couple the working hydraulics to the working quick couplings (EW / two couplings).
¾ Lower coupled implements when you stop the transporter.
5.2 Decoupling
¾Place the implement on a flat and solid underground.
¾Decouple all hydraulic hoses.
¾Put protection caps and plugs in when the implements are decoupled.
¾Disconnect all pins and strips.
5.3 Instructions towing the machine
¾Shift the reduction in the rear axle in the neutral position (high/low gearing) (lever 12).
¾Use the parking brake (13) when you must stop.
¾Maximum speed at towing is 3 km/h.
) IMPORTANT! Don’t tip the platform backward when the rear lift is mounted!
