Usermanual NIMOS Micro-Trac Page 6
1.3 Technical dates
Type:
Micro-Trac
Motor:
o Air cooled HONDA Gasoline engine GX620, 2-cilinder 14,9 kW (20 hp) at 3600
rpm, 44,1 Nm at 2500 rpm.
o Liquid cooled Yanmar diesel engine 3TNE68 3600rpm 14,6kw(21,5hp)
Transmission:
Fully hydrostatic driven, with one pedal operation for forward and backward driving
automatically control of engine Rpm
Brake system:
o Brakes: hydrostatic en disk brake.
o Parking brake: disk brake.
Speed:
High speed: 0-25 km/h
Low speed: 0-13 km/h
Pumps:
Hydraulics of the charging pump of the hydrostatic transmission hydrostatic
transmission.
Optional: extra PTO-pomp (5,8 cc. - 21 l/min at 3600 rpm.)
Steering:
Hydraulics.
Steering circel:
Outer diameter 2050 mm
Inner diameter 680 mm
Tyres:
Front: 18x 9.50- 4ply.
Back: 23x10.50- 4ply.
Tyre pressure:
- minimum
- small load
- heavy load
front
1,0 bar
1,0 bar
1,0 bar
back
1,0 bar
1,2 bar
1,4 bar
Cabin:
Control platform: open control platform with spring seat, weight adjustable.
Cabin with roof and front window, doors and heating optional.
Dimensions:
- length
- wide
- height
2900 mm
1180 mm
1440 mm
Loading floor:(inner
space)
- length
- wide
- height
1560 mm
1100 mm
300 mm
Tipping unit capacity:
0,52 m
3
Wheel base:
1500 mm
Track wide:
845 mm
Total weight:
1700 kg
Loading capacity:
1000 kg
Machine weight:
700 kg (standard)
1.4 Type plate
Ident. nr.: serial number;
Type: type;
Bouwjaar: year of production;
Eigen massa: netto weight;
Nom. vermogen: maximum power;
Maximum massa: total weight;
Max. aslast voor: weight front axle;
Max. aslast achter: weight rear axle
.
