6.1 Configure the installation file
From the Processor Regatta home page press «configuration» to access the file
« Instal.ini ».
The path for this file is:
ftp://root:pass@192.168.0.232/mnt/flash/processor/instal .
This file controls the configuration of your Processor Regatta. It contains two sections.
[Language]
Language = 1 ; Gyropilot Graphic secondary language (0=French
1=English)
Performance = Y ; Performance calculus form polars Broadcasts the
performance data of the polar in processor memory on the Topline Bus.
Declination = Y ; Declination calculus Calculation of the declination from the table
in memory.
[Datalog]
ValidDatalog = Y ; Valid datalog (Y or N) Data recording on the USB stick.
[NMEA1]
ValidNmea1 = Y ; Valid NMEA1 Validates the input to which the compass is
connected. Automatic detection by default.
InstalNmea1 = 255 ; Type of compass sensor
; 7 = 3D Sensor
; 10 = Regatta Compass
; 11 = KVH Compass
; 13 = 3D Fusion
; 255 = AUTODETECT
BaudrateNmea1 = 4800 ; Baudrate of datas (if AUTOTEDECT is off)
[NMEA2] NMEA input output setting
ValidNmea2In = N ; Valid NMEA2 input (serial NMEA0183)
ValidNmea2Out = N ; Valid NMEA2 output (serial NMEA0183)
BaudrateNmea2 = 4800 ; baudrate NMEA183IN&OUT
[NMEAUdp] UDP input output setting
ValidUdpNmeaIn = N ; Valid NMEA183 input on UDP/IP
UdpNmeaInPort = 1001 ; UDP Port number for NMEA183 input on UDP/IP
ValidUdpNmeaOut= N ; Valid NMEA183 output on UDP/IP
UdpNmeaOutPort = 1000 ; UDP Port number for NMEA183 output on UDP/IP
UdpNmeaOutIP = 192.168.0.255 ; Recipient IP address (navigation PC)
(x.x.x.255 to broadcast)
[SailNet]
ValidSailNet = N ; Valid SailNet (IP variables synchronisation)
WARNING
The default configuration of this file is correct but you can apply modifications should
you want to customize your system.
Modifications are saved by pressing « Save File » and will be applied after you reboot
the Processor Regatta. This is done by pressing « Reboot » in the « Action » section.
