5.1 Installation of a brand new nke system
All units except the Processor Regatta must be installed first. Please refer to the manual
for each unit (sensors, displays…). We recommend using the Mutltigraphic or
Gyrographic as the system’s Master.
Once the system is installed, refer to “How to integrate Processor Regatta in an existing
nke system” to complete the installation.
5.2 Installation of the Processor Regatta with an existing nke system
As a first step, you need to update every component connected to the Topline network.
This is done with the « Toplink2 » software, or alternatively you can send the units to nke
customer support.
Firmware, database and the Toplink2 software (requires the Topline USB interface 90-60-
482) are all available for download at the following address: http://www.nke-marine-
electronics.com in the technical area (requires a password – access to trade only).
Table of compatibility with the Processor Regatta:
Type of unit Description
Minimum Version
required
Display Multigraphic All versions
Display Multidisplay All Versions
Display Gyropilot Graphic V3.1
Display TL25 V1.5
Display Display and Pilot PAD All versions
Interface Toplink 2 V2.0.11
Interface Radio receiver V2.4
Interface Wifi Box All versions
Interface Battery monitor 500 All versions
Interface Speed and depth Interface V2.0
Interface Dual-speed and depth Interface V2.0
Interface Interface Loch for paddle wheel V2.2
Interface Interface sounder V2.2
Interface Analog Monitor All versions
Interface Analog Monitor 4X All Versions
Interface Load Cell Monitor All Versions
Interface Regatta Compass Interface V1.4
Sensor Ultrasonic starboard / port V1.6
Sensor Fluxgate compass N.C
Sensor Carbowind HR V1.8
Sensor AG HR V1.8
Sensor 9X Compass All versions
Sensor 3D Sensor V2 & V3
Sensor HR 100 barometric sensor V1.0
Autopilot Pilot processor V3.0
Once you have ensured that all units are up to date with a compatible version, you can
power the system on and check that it works properly. We strongly recommend choosing a
