TWA
4
6
8
10
12
14
16
20
25
30
33
2.761 4.076 5.08 5.624 5.904 6.044 6.107 6.104 5.84 5.176
36
3.043 4.448 5.475 5.975 6.23 6.354 6.422 6.446 6.28 5.802
39
3.302 4.782 5.806 6.259 6.477 6.587 6.654 6.694 6.594 6.277
50
4.07 5.688 6.572 6.882 7.052 7.172 7.26 7.361 7.368 7.256
60
4.541 6.156 6.918 7.251 7.437 7.581 7.695 7.85 7.932 7.899
70
4.821 6.383 7.107 7.542 7.762 7.942 8.101 8.352 8.534 8.583
80
4.925 6.456 7.206 7.708 8.063 8.308 8.524 8.876 9.223 9.434
90
4.974 6.664 7.422 7.796 8.253 8.662 8.949 9.526 10.134 10.566
105
5.055 6.682 7.495 8.106 8.559 8.962 9.404 10.567 11.631 12.578
120
4.695 6.456 7.339 7.943 8.679 9.454 10.104 11.327 13.237 15.149
135
4.085 5.849 6.926 7.676 8.433 9.235 10.102 12.202 14.791 17.174
140
3.805 5.538 6.723 7.491 8.213 9.048 10.07 11.912 15.335 17.898
150
3.246 4.833 6.166 7.019 7.683 8.373 9.187 11.582 15.493 18.583
165
2.494 3.77 4.988 6.076 6.876 7.511 8.122 9.662 12.464 16.247
The polar table file has the « .pol » extension. The maximum format is 32 lines for 17
columns, tabulation separator and point decimal sign.
If that format is not followed, an error message will appear in the log file of the Regatta
Processor.
9.2 Reading a polar diagram
The diagram below shows both sides, but usually, only the port side is shown, as both
tacks should be same.
The boat line is vertical, with the bow on the top. The radiuses feature the true wind angle.
Each curve represents the boat speed for a given wind speed.
