To measure the Apparent Wind Angle you can use the tools of performance software or
achieve the calculation on your own using the data logged on the USB key embedded in
the Processor Regatta, or alternatively use the application of the Gyropilot Graphic.
Warning! If you work with software such as « Tactique » from Adrena, the offset is
calculated from the function « Apparent Wind Angle ». This function is reverse calculated
from the true wind angle and damped for display. Therefore the true wind table needs to
be reset as well as the wind shear and you have to apply the offset to the existing value if
different from 0.
The l nke calibration wizard uses the raw data
Apply the offset with the Multigraphic or Multidisplay :
Page ► Sensors ►App wind angle ► Offset
AWA port > AWA starbord :
Add half the difference between the two values
If AWA port < AWA starboard:
Substract half the difference between the two values
AWA 27°AWA -24°
