PAGE 2-12
CHAPTER 1 GENERAL INFORMATION AND OPERATING INSTRUCTIONS
NMC-WOLLARD
2021 Truax Blvd. Eau Claire, WI 54703 ● P: 715-835-3151● F: 715-835-6625 ● www.nmc-wollard.com
TML-704H Maintenance Lift Manual No. 310547
2 OPERATION
FIGURE 2. MANUAL OVERRIDE OPERATION
2.3.8 Towing the Maintenance Lift
If there is a failure in the engine/power train and the unit must be towed,
retract the stabilizers and disconnect the drive shaft (or raise rear wheels
o the ground). This will prevent damage to the transmission while towing.
Towing speed must not exceed 10 miles per hour.
SEPTEMBER 01, 2015
Operate Safety Valve (SV3)
Stabilizers Directional
Control Valve (SV2)
Platform Lift Cylinders
Directional Control Valve ( SV1)
Override Knob
Override Knob
Property of American Airlines
