PAGE 3-1
CHAPTER 1 GENERAL INFORMATION AND OPERATING INSTRUCTIONS
NMC-WOLLARD
2021 Truax Blvd. Eau Claire, WI 54703 ● P: 715-835-3151● F: 715-835-6625 ● www.nmc-wollard.com
TML-704H Maintenance Lift Manual No. 310547
3. SPECIFICATIONS AND CAPABILITIES
Chassis
Frame ......................................................... welded steel tubular construction
Wheelbase......................................................................130 inches (330 cm)
Vehicle Speed ................................... 20 MPH (32 KPH) (All engine options)
Turning Radius ........................................................................ 22 feet (6.7 m)
Ground Clearance .......................................................... 7.75 inches (20 cm)
Work Platform
Construction: Welded frame of high-strength structural steel with aluminum
Gripstrut deck.
Heights
Platform Floor Full Down ...............................................................4’-9” [1.4m]
Platform Floor Full Up .................................................................30’-0” [9.1m]
Dimensions
17’-6” (5.3 m) long; 6’ 10” (2.1 m) wide. (220 sq.ft), less operation station cutout
for a total usable area of 109 sq. ft. (10.15 m2)
Platform Load Capacity
.................................................2,000 lbs. (867 kg.) total, uniformly distributed
.................................................250lbs./sq.ft. (122 kg/sq.m) concentrated load
Engine
Packages available for the TML-704H:
• Deutz 2011F in-line, 4-cylinder diesel, 4-cycle, 59 hp at 2600 rpm, 167 in3
(2.7L) displacement, oil cooled.
• Cummins B3.3 diesel
• Kubota WG2503 gas
• Kubota V2203 diesel
Transmission
Type .................................................................................................Automatic
Capacity ............... 9.5 U.S. quarts, automatic trnasmission uid, ATF, type F
3 SPECIFICATIONS AND CAPABILITIES
OCTOBER 10, 2017
Property of American Airlines
