PAGE 3-2
CHAPTER 1 GENERAL INFORMATION AND OPERATING INSTRUCTIONS
NMC-WOLLARD
2021 Truax Blvd. Eau Claire, WI 54703 ● P: 715-835-3151● F: 715-835-6625 ● www.nmc-wollard.com
TML-704H Maintenance Lift Manual No. 310547
Drive Axle
Type ............................................................................................. Automotive
Capacity .......................................................................... 3,300 lbs (1,497kg)
Lubrication ............................... See Chapter 2 for specication and capacity
Steering Axle
Type ....................................................Automotive type, non-drive, steerable
Capacity .......................................................................................... 6,800 lbs
Tires ............................................................................... Front 8.75R-16.5/10
........................................................................................ Rear ST225/75D15
Inatable pressure ............................................................... 80 psi (cold)Front
Inatable pressure ................................................................65 psi (cold)Rear
Lug nut torque .................................................................................. 120 ft-lbs
Brakes
System .......................................................................... 4-wheel split cylinder
Front ................................................................................................. Disc type
Rear ................................................................................................Drum type
Parking ................................................................Orscheln lever, rear wheels
Electrical System
Type ........................................................................ 12 VDC, negative ground
Alternator ........................................................................................61 Ampere
Battery .................................................. 900 amperes, cold crank, group 4D
Fuel Tank ...................................................... Electric gauge and vented cap
................................................. See Chapter 2 for specication and capacity
Cooling System
Engine .....................................See Chapter 2 for specication and capacity
Steering System
Type ......................................................... Power steering; Char-Lynn Orbitrol
Cylinder ..................................................................... Double Acting hydraulic
3 SPECIFICATIONS AND CAPABILITIES
SEPTEMBER 01, 2015
Property of American Airlines
