PAGE 3-3
CHAPTER 1 GENERAL INFORMATION AND OPERATING INSTRUCTIONS
NMC-WOLLARD
2021 Truax Blvd. Eau Claire, WI 54703 ● P: 715-835-3151● F: 715-835-6625 ● www.nmc-wollard.com
TML-704H Maintenance Lift Manual No. 310547
3 SPECIFICATIONS AND CAPABILITES
Hydraulic System
Lift cylinders ........................................................................ Single-acting (lift)
Stabilizer Cylinder ................................................... Double-acting (stabilizer)
Valves .................................................................................Solenoid actuated
Pumps ............................................................................ Main, Engine-driven
............................................................................. Emergency: electric driven
System pressure ........................................ 1,800 psi max. (126.5 kg/sq.cm.)
Filter ........................................In return line, 10 micron, replaceable element
Strainer .....................................................................In suction line, 50 mesh
Hydraulic reservoir .................................... sight gauge and breather/strainer
................................................. See Chapter 2 for specication and capacity
Instrumentation
Warning lights ........................................................... Volts, Oil, Water, Brakes
On-O󰀨 switches: Anti-crank start, Running lights,glow plugs(for cold starting)
Hour Meter ....................................................... Records engine running time
Fuel Gauge .......................................................................................... Electric
Controls
Momentary Switches .........................Platform Up/Down, Stabilizer Up/Down
.........................................................................Operational (Platform) Safety
SEPTEMBER 01, 2015
