CHAPTER 4 REPAIR PARTS AUGUST 31, 2005
4 ILLUSTRATED PARTS LIST PAGE 3
Truck Mounted Passenger Stair TMPS-200 Manual No. 307559
Fig.-
Item
NMC-
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Unit
s
Per
Assy
1- 307554 Base Group, 1 of 2 Ref
2 See Appropriate Truck Prep Page In this
Chapter.
1
6 12645 Bolt, Stair 1
7 12681W A-Frame Assembly (See Figure 2) 1
8 12708W Main Stair Assembly (See Figure 3) 1
9 304454 Handrail, Main Stair (See Figure 4) 2
10 12651 Adjustable Stair Assembly (See Figure 5) 1
11 5474 Handrail, Adj. Stair Assy (See Figure 7) 2
12 Latch Assembly, Stair Tread Ref
13 12751W Solenoid Installation (See Figure 16) Ref
14 12794 Stabilizer, Main (See Figure 8) 2
15 12803W Stabilizer, Rear (See Figure 9) 2
16 9.2091 Trim, Rubber, 3/32" 75"
20 3.0395 Nut, Lock, 1"-8 USS 1
22 Comm HHCS, 3/8-16 x 1.50" 6
26 3.0539 HHCS, 1-14 x 3.00" SAE 2
27 3.0540 HHCS, 1-14 x 3.50" SAE 2
28 3.1662 Nut, Lock, Jam, 1-14 SAE 4
31 Comm Screw, TEK, HH, Self-drill, 1/4-20 x 0.75" 6
32 307558 Frame Weldment, Stair Support F350 1
36 12655.20 U-Bolt, Sq., 3/4-10 x 3.5"ID x 14.2 1
37 12655.04 U-Bolt, Sq., 3/4-10 x 10-1/2" x 3.50" (Fwd
LH)
1
38 12654.02 U-Bolt, Rd, 3/4 x 25 x 5.50" (Axle) 2
40 3.0393 Nut, Lock, 3/4-10 USS 10
41 3.0381 Nut, Hex, 3/4-10 4
43 3.0307 Flat Washer, 3/4 SAE 16
45 Comm Nut, Lock, 3/8-16 6
46 3.2766 Washer, 3/8" 6
47 16768.2 Panel Weldment, RH 1
303986 Panel Weldment, LH 1
49 12679W Placards and Signs (See Figure 17) 1
50 12655.08 U-Bolt, Sq., 3/4-10 x 15 x 3.50" AFT 1
51 303742 Bracket, Taillight, RH 1
52 303773 Bracket, Taillight, LH 1
53 Comm Screw, TEK, 1/4 x 1.00 16
To Next Page
