3 SPECIFICATIONS AND CAPABILITIES
3.1 AIRCRAFT SERVICING CAPABILITY - 2005 & LATER
All Aircraft having doorsill heights ranging from 100” (254cm) to 200” (508cm).
3.1.1 Stair Capacity
Platform ...............900 lbs. (409 kg) uniformly distributed load
Each Step ...............................200 lbs.
3.1.2 Height Range
Low Position ..........................100 in. (254 cm)
High Position..........................200 in. (508 cm)
3.1.3 Dimensions
Nominal tread depth......................10.05 in. (26 cm)
Nominal tread width (lower section) ...............42 in. (107 cm)
Nominal tread width (upper section) ..............47 in. (119 cm)
Top platform width .......................64 in. (163 cm)
Top platform depth .......................84 in. (213 cm)
Intermediate landing depth ..................19.75 in. (50 cm)
Constant riser height ......................7.85 in. (20 cm)
3.1.4 Shipping Dimensions
Length .............................288 in. (7.32 m)
Width .............................90.7 in. (2.30 m)
Height .............................145 in. (368 cm)
Weight ..........................11,000 lbs. (4,990 kg)
3.1.5 Operator Controls
Indicators ..................power, stabilizers down, stair lights
Switches............power, stair lights, “A” frame and Stair interlocks
A-frame and Stair UP/DOWN and Stabilizers UP/DOWN
3.1.6 Vehicle (standard)
Ford F-350, V-8 engine, automatic transmission, 11,000 lbs. (4990 kg) GVW,
power steering
