CHAPTER 4 REPAIR PARTS AUGUST 31, 2005
4 ILLUSTRATED PARTS LIST PAGE 7
Truck Mounted Passenger Stair TMPS-200 Manual No. 307559
Fig.-
Item
NMC-
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
2- 12681W A-Frame Assembly Ref
2 12682 Frame, Upper 1
3 12683 Frame, Lower 1
4 12675 Arm, Release 1
5 12681.5 Shaft, Pawl 1
6 12668 Pawl, A-Frame 2
7 Comm Washer, 3/4" 4
8 Comm HHCS, 1/4-20 x 0.75" 2
9 Comm Pin, Clevis, 1/4 x 23/32" Grip 1
10 Comm Pin, Cotter, 1/16 x ½", SS 1
11 Comm Washer, 1/4" 3
12 Comm Grease Fitting, 1/4"-28, Straight 4
13 1.0757 Spring, 3/8" O.D. x 8" Lg. 1
16 12681.16 Spacer 4
17 Comm Nut, Lock, 1/4-20 2
18 Comm Capscrew, 3.50" Lg. Ref
19 Comm Nut, Lock Jam Ref
20 Comm Capscrew, 3.00" Lg. Ref
To Next Page
