CHAPTER 4 REPAIR PARTS MARCH 31, 2007
4 ILLUSTRATED PARTS LIST PAGE 13
Truck Mounted Passenger Stair TMPS-200 Manual No. 307559
Fig.-
Item
NMC-
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
4- 304454L Handrail Assy, LH Ref
304454R Handrail Assy, RH Ref
2 304461L Pipe, Handrail, LH 1
304461R Pipe, Handrail, RH 1
3 6259 Pad, Stanchion, Drilled 6
4 302999 Plug, Pipe, Alum, 1.25 E 2
302999 Plug, Pipe, Alum, 1.25 F 1
5 5699 Post, Vertical, Handrail 1
6 5679 Post, Vertical, Handrail 5
7 7352 Plate, Nut 6
8 12749 Brkt, Handrail Mntg 1
9 Comm HHCS, 1/4-28 x 1 6
10 Comm HHCS, 1/4-28 x 1-1/4 6
11 3.0505 HHCS 3/8-24 x 17 5
12 Comm HHCS, 3/8-24 x 7 1
13 Comm Washer, 3/8 6
14 Comm Nut, 1/4-28 2
15 3.0459 HHCS 3/4-10 x 3 2
16 3.0308 FW 3/4 USS ZP 2
17 3.0393 Nut Lock 3/4 US 2
