NMC-WOLLARD TMPS-200 - Page 133

CHAPTER 4 REPAIR PARTS AUGUST 31, 2005
4 ILLUSTRATED PARTS LIST PAGE 15
Truck Mounted Passenger Stair TMPS-200 Manual No. 307559
Fig.-
Item
NMC-
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
5- 12651 Adjustable Stair Assembly, 1 of 3 Ref
0 12716 Structure, Adjustable Stair 1
3 12520 Skin, Outer 2
6 13219 Wing Assembly (See Figure 6) 2
7 305742 Extrusion, 1 Die, 3/8 x 2 x 15' 2
8 12738 Bumper 1
9 12739W Retainer, Bumper 1
11 12651.11 Extrusion 2
12 303590 Safety Stop 18
13 5474 Handrail, Adjustable Section (See Figure
7)
2
14 12129 Stop, Wing 4
15 12624.01 Track, Lower, LH 1
16 12624.02 Track, Lower, RH 1
17 302967 Extrusion 2
18 12524 Spacer, Skin 12
19 12741 Spacer, Skin, 1.5 x 5.5 6
20 12770.01 Hat Section, Long 8
21 12770.04 Hat Section, Short 2
22 17678.01 Tread, Adjustable Section 9
23 17679.02 Riser, Adjustable Section 9
24 12737W Deck Plate, RH 1
25 12736W Deck Plate, LH 1
26 12744W Deck Plate, Center 1
27 17677 Angle, Riser 18
28 17676 Angle, Tread 18
29 12733 Support, Tread 1
30 12770.05 Spacer 10
50 Comm Screw, Pan HD Mach, #10-32NF x 1-7/8 36
51 Comm Nut, Lock, #10-32NF 36
52 Comm HHCS, 1/4-20 x 1.25 18
53 Comm Nut, Lock, 3/8-16 27
54 Comm HHCS, 3/8-16 x 1.00 11
55 Comm Washer, Flat, 3/8 USS 23
56 12651.56 Angle 2
60 Comm Nut, Lock, 1/4-20 20
61 Comm HHCS, 1/4-20 x 2.00 4
62 Comm Rivet, RD HD Alum, #6-8 A/R
63 Comm Washer, Flat, 1/4 38
