CHAPTER 4 REPAIR PARTS AUGUST 31, 2005
4 ILLUSTRATED PARTS LIST PAGE 19
Truck Mounted Passenger Stair TMPS-200 Manual No. 307559
Fig.-
Item
NMC-
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
5- 12651 Adjustable Stair Assembly, 3 of 3 Ref
6 13219 Wing Assy (See Figure 6) 2
15 12624.01 Track, Lower, LH 1
31 300268 Extrusion 2
32 12538 Side Cap, Platform 2
33 12589.01 Corner Cap, LH 1
34 12589.02 Corner Cap, RH 1
39 12591W Bracket 2
40 12743W Angle, Mounting 2
41 8869 Slide Block, Wing 4
42 3741 Latch Pivot 2
43 12651.43 Spacer 1
44 5664 Plate, Backup 2
45 7916 Track Support, Upper 4
46 5665 Latch, Wing Lock 2
47 5662 Latch Spring, LH 1
48 5663 Latch Spring, RH 1
49 Comm Bolt, Clevis 2
53 Comm Nut, Lock, 3/8-16 27
54 Comm HHCS, 3/8-16 x 1.00 11
55 Comm Washer, Flat, 3/8 USS 23
59 Comm HHCS, 1/4-20 x 1.50 44
60 Comm Nut, Lock, 1/4-20 20
63 Comm Washer, Flat, 1/4 38
64 Comm HHCS, 1/4-20 x 1.00 14
65 Comm RHMS, #10-24 x 0.75 6
66 Comm Nut, Lock, #10-24 8
67 Comm Washer, Flat, #10 8
68 Comm RHMS, #10-24 x 1.25 2
69 Comm Nut, Lock, Thin, ½-20 2
70 Comm Washer 2
71 Comm Rivet, RD HD Alum, #4-6 A/R
76 19450 End Panel, LH 1
77 19473 End Panel, RH 1
78 19474 Angle, Light Mounting 1
80 303485 Handle w/ 3/8" Lockwasher (NS) 1
81 Comm Lockwasher, 3/8 2
To Next Page
