NMC-WOLLARD TMPS-200 - Page 139

CHAPTER 4 REPAIR PARTS AUGUST 31, 2005
4 ILLUSTRATED PARTS LIST PAGE 21
Truck Mounted Passenger Stair TMPS-200 Manual No. 307559
Fig.-
Item
NMC-
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
6- 13219 Wing Assembly, Platform Ref
2 9433 Frame, Wing 1
3 9436 Wheel 2
6 300029 Bolt, Carriage, 3/8-16 x 4.00 2
7 305157 Nut, Jam, Lock, 3/8-16 6
8 300028 Bolt, Carriage, 3/8-16 x 2.50 4
9 F100062 Washer, Flat, 3/8, USS 6
10 13219.10 Tube, Hydraulic, ½" OD x .049 Wall x
1-17/32"
2
11 9319 Track, Notched 2
12 13219.12 Spacer 5
13 Comm Screw, HH Self-Drill, 1/4 x 2.50 5
14 9439 Bumper 2
15 14773 Guard, Wing 2
16 12128 Support, Wheel 2
17 302591 Rivet, Pop, 3/16 x .902 22
NS F100360 HHCS 1/4-20 x 1.5 GR 5 5
NS F009535 LW 1/4 Reg 5
