CHAPTER 4 REPAIR PARTS AUGUST 31, 2005
4 ILLUSTRATED PARTS LIST PAGE 23
Truck Mounted Passenger Stair TMPS-200 Manual No. 307559
Fig.-
Item
NMC-
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
7- 5474 Adjustable Section Handrail Ref
2 307373 Handrail, Upper Adj. 1
3 6259 Pad, Stanchion 4
4 302999 Plug, Railing 2
5 5699 Post, Vertical 4
7 7352 Nut, Plate 4
9 Comm HHCS, 1/4-28 x 1.25 6
10 Comm HHCS, 1/4-28 x 1.25 2
11 Comm HHCS, 3/8-24 x 7.00 4
12 Comm Washer, 3/8 4
13 Comm HHCS, 1/4-28 x 1.50 2
14 Comm Nut, Lock, 1/4-28 2
To Next Page
