NMC-WOLLARD TMPS-200 - Page 143

CHAPTER 4 REPAIR PARTS AUGUST 31, 2005
4 ILLUSTRATED PARTS LIST PAGE 25
Truck Mounted Passenger Stair TMPS-200 Manual No. 307559
Fig.-
Item
NMC-
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
8- 12794 Main Stabilizer Assembly Ref
2 12789W Tube, Lower 1
3 12793W Tube, Upper 1
4 304106 Shoe Weldment Stabilizer 2
302964 Shoe Weldment, Stabilizer, Super-Duty Ref
5 12817 Cylinder Ref
6 12762W Link, Stabilizer 2
7 12794.7 Shaft, Hydraulic Cylinder Top 1
8 12792W Shaft, Upper Tube Pivot 1
9 Comm Cotter Pin, 3/16 x 1.25 8
10 3.0296 Washer, Flat, 1" I.D. 8
11 12794.11 Spacer 4
13 302490 Switch, Proximity (LH Only) (See Fig. 15) Ref
