CHAPTER 4 REPAIR PARTS MARCH 31, 2008
4 ILLUSTRATED PARTS LIST PAGE 29
Truck Mounted Passenger Stair TMPS-200 Manual No. 307559
Fig.-
Item
NMC-
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
10- 307555 Hydraulic Assembly Ref
2 18039 Cyl, 1 1/8R x 2B x 9S 2
300231 5200-148 Kit, Seal 5200-148 A/R
3 12817 Cylinder, 1 1/4R x 2 1/2B x 12S 2
1.7957 5200-268 Kit, Seal A/R
4 8766 Cylinder, 2 1/2R x 3B x 118 1/2S 1
1.7599 5200-173 Kit, Seal A/R
5 12819 Cylinder, 1 1/2R x 3 1/2B x 18 1/2S 1
1.7913 5200-209 Kit, Seal A/R
9 307616 Tube, Hyd G 2
10 3.2625 Ftg, Hyd, Plug, 06MB 1
11 154074 Ftg, Hyd, 06MP-06FP90 C 2
12 3.2212 Ftg, Hyd, 06FP-06FP 2
13 3.1572 2021-6-6 Ftg, Hyd, 06MJ-06MP (01276) 2
14 3.1926 2024-6-88-6 Ftg, Hyd, Ell, 06MJ-08MB 2
16 202074 Ftg, Hyd, 08MJ-10MB45 1
17 3.1317 2024-6-8 Ftg, Hyd, Ell, 08MJ-06MP90 (01276) 2
18 3.1630 2028-6-8 Ftg, Hyd, Tee, 08MJ-06MP-08MJ 1
19 NW036178 Ftg, Hyd, Plug, 04MB 3
20 1.0906 F25B Valve, Flow Control, 06 (29771) 1
21 3.1386 2085-8-6S Ftg, Hyd, 08MP-06MP90 2
22 3.1564 2024-6-6S Ftg, Hyd,06MJ-06MP90 4
23 8946.24 Hose Assy, #08M, 143.72” LG 1
24 306408 Valve, PO Check, 06 4
28 303618 Handle, Handpump 1
29 307575 Manifold, Lift/Stabilizer (See Fig 13) 1
30 307596 Tank Assy, Hydraulic (SN 1380+)(See
Fig. 11)
Ref
5456 Tank Assy, Hydraulic (SN 1378-1379)
(See Fig. 12)
32 3.1535 Ftg, Hyd, Tee, 06MJ-04MP-06MJ 4
33 NW031415 Ftg, Hyd, 06MP-06FP45 G 4
35 3.1566 2024-8-8S Ftg, Hyd, 08MJ-08MP90 (01276) 2
37 3.1389 2083-6-8 Ftg, Hyd, 08MP-06MP (01276) 2
38 3.2143 2071-6-6S Ftg, Hyd, 06MJ-06FJ90 (01276) 3
39 3.2878 Ftg, Hyd, 06MJ-06MB90 5
40 307617 Ftg, Hyd, 06MJ-06MBL 1
41 91930 Ftg, Hyd, 08MJ-08MB90 2
42 90375 Ftg, Hyd, 08MJLL-08MB90 1
43 3.2518 202702-6-6
S
Ftg, Hyd, 06MJ-06MB (01276) 2
44 3.2703 Ftg, Hyd, 08MJ-10MB 1
45 8796.85 Hose Assy, #06M, 106.54” LG 1
46 8946.7 Hose Assy, #08M, 42.72” LG 1
47 8946.1 Hose Assy, #08M, 68.72” LG 1
48 8797.96 Hose Assy, #08M, 181.00” LG 1
49 8797.9 Hose Assy, #08M, 50.08” LG 1
50 8945.75 Hose Assy, #06M, 151.14” LG 2
