NMC-WOLLARD TMPS-200 - Page 151

CHAPTER 4 REPAIR PARTS JANUARY 31, 2014
4 ILLUSTRATED PARTS LIST PAGE 33
Truck Mounted Passenger Stair TMPS-200 Manual No. 307559
Fig.-
Item
NMC-
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
11- 307596 Tank Assy, Hyd. TMPS200 D Ref
1 1.9008 9690217 Gauge, Pressure, 0-30 PSI, 1/8NPT 1
2 1.8090 FBA108W Fill Unit, W/ Strainer, A115W 1
3 3.1568 2501-08-12 Ftg, Hyd, 08MJ-12MP90 1
4 1.7162 MDP-105 Plug Magnetic Drain, 3/4 NPT 1
5 1.7146 F99Z136004 Valve, Gate, 1 NPT Female 1
6 1.0437 FPC30 Filter, Hyd, Return, 3/4"NPT 1
7 1.3712 Element, Hyd Filter 1
8 3.0935 Nipple, 1" NPT Close, SCH 40, BIP 2
9 45458 4503-16-16 Ftg, PHyd, 16H-16MP45 1
10 3.0915 Ftg, P, N, 12MP-5"L, BIP 1
11 1.8943 Strainer, Y, 1" NPT, 80 Mesh, BIP 1
12 F009591 RHMS, #10-24 x 3/4, SL, ZC 10
13 3.0888 65-104 Ftg, P, Ell, 12PF, BIP, SCH40 1
14 307606 G605-07-A-1 Gauge, Sight, 7" Frnt Mnt, ½-20 1
15 307230 402-007 Ftg, P, Tee, 12SLP-12SLP-12FP, PVC
402-007 Nibco
1
16 307594 Cover Weldment, Hyd Tank 1
17 307602 Gasket, Hyd Tank Cover, TMPS200 1
18 307591 Tank, Hyd, TMPS200, Cleaned 1
19 306580 Nutsert, #10-24, Closed End 10
