CHAPTER 4 REPAIR PARTS SEPTEMBER 30, 2008
4 ILLUSTRATED PARTS LIST PAGE 37
Truck Mounted Passenger Stair TMPS-200 Manual No. 307559
Fig.-
Item
NMC-
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
12- 307575 Manifold, Lift/Stabilizer 1
1 308883 CP08-20-N Plug 3
2 308849 CV10-20-0-N
-02
Check Valve 1
3 308850 CV08-20-0-N
-04
Check Valve, 4 PSI 1
4 308851 CV08-20-0-N
-150
Check Valve, 150 PSI 1
5 308884 FR12-30F-0-
N
Regulator, Pressure Comp. 1
6 307547 HP10-21A-0-
N-B
Hand Pump, Push Handle,
.65 cu in/Stroke
1
7 307497 PC10-30-0-N Check, Pilot to Open 1
8 308852 RV10-22A-0-
N-25/12
Relief, Differential Area Poppit,
250-2400 PSI
1
9 305745 SV10-47DM-
0-N-00
Spool, 4 Way, 3 Pos 1
10 308847 SV10-47CM-
0-N-00
Spool, 4 Way, 3 Pos, Closed Center 2
11 308848 SV08-21-0-N
-00
Poppit, 2 Way, Normally Open 1
12 307610 6309737 Coil, Solenoid Valve, Small 1
13 307611 6359732 Coil, Solenoid Valve, Large 6
14 308885 7063130 Orifice Disc 2
15 308886 6103004 Port Plug 11
16 308887 6103006 Port Plug 2
17 308888 6103008 Port Plug 5
18 308890 7274010 Block 1
20 308889 3108080 Plug 13
NS F002547 Pin, Cotter 1/8x2 (thru manual over
ride holes)
3
