CHAPTER 4 REPAIR PARTS MARCH 31, 2008
4 ILLUSTRATED PARTS LIST PAGE 43
Truck Mounted Passenger Stair TMPS-200 Manual No. 307559
Fig.-
Item
nmc-
wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
15- 307556 Electrical Assembly, 2 of 3 Ref
1 2.1401 Stancor
70-902
Relay,Power,SPNO,12VDC/80A 1
2 2.0985 SDLA-70 Breaker,Circuit,70A Auto-Reset 1
3 2.1941 30056-40 Breaker,Circuit,40A Auto-Reset 1
4 2.3543 30056-25 Breaker,Circuit,25A Auto-Reset 1
5 2.3451 30090-3 Holder, Circuit Breaker,3-Gang 1
6 2.0311 245 Flasher,3-Wire,Independent,12V 1
7 2.2441 RB08-PC Socket,Relay,8-Pin 1
8 2.2440 RR2P-UD
C12VDC
Relay, Plug-In,8-Pin,12 VDC 1
9 2.3648 150-905 Relay,12VDC,SPDT,15A,Enclosed 1
10 2.0021 Buchanan
924
Block, Terminal 6
11 2.0022 530 Terminal End (83079) 1
12 2.3093 NTE 5805 Diode,3A,200V,Axial Lead 3
13 307607 Enclosure, Modified,TMPS200 1
14 307608 Panel,Modified,12x6x4,TMPS 1
15 2.0180 OZGSR50
625
Connector, Cord ½" Hub 1
16 303247 A-HCI10E Inhibitor Corrosion 1
17 3.0282 AN931-6-
10
Grommet, 0.38ID, 0.63HD, 1/16 Grv 1
18 2.3648 Relay, Opt 1
19 302490 972AA3X
M-B3P-L
Switch, Proximity, SPNC (91929) 1
NS 2.3639 Connector, Butt 3
NS 3.0284 Grommet, .63ID, .88 HD 1
NS 2.1033 Wire 6 GA Blk SGX 120”
NS 3.2827 Grommet, .25 ID, .44 HD 1
