CHAPTER 4 REPAIR PARTS MARCH 31, 2008
4 ILLUSTRATED PARTS LIST PAGE 45
Truck Mounted Passenger Stair TMPS-200 Manual No. 307559
Fig.-
Item
NMC-
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
15- 307556 Electrical Assembly, 3 of 3 Ref
1 NW035381 595902 Frame, 6 Switch 1
2 NW036731 594802 Holder, Switch, End Piece 2
3 NW034176 511005 Switch, Rocker, Off-On, SPST 2
4 NW035377 511-056 Switch, Rocker, Mom-Off-Mom 3
5 NW035374 511008 Switch, Rocker, Off-Mom. On 2
6 306213 Insert, Switch, No Shift, Red 1
7 NW035382 596620 Insert, Switch, Blank, Black 3
8 307562 594405 Insert, Switch, Up/Dwn. Gn 1
9 307565 594499 Insert, Switch Release, Red 2
10 307564 595105 Insert, Switch, Stair Lts, Gn 1
11 NW035378 511502 Housing, Light Indicator, 2-Lamp 1
12 307560 596204 Insert, Switch, Stair, Gn 1
13 307561 596157 Insert, Switch, Stabilizer, Gn 1
14 307563 594421 Insert, Switch, Power, Red 1
15 307585 Decal, Controls, Elec, TMPS200 1
NS 37409 913328 Connector, Light 3
NS 37408 596289 Connector, Switch 7
