CHAPTER 4 REPAIR PARTS MARCH 31, 2008
4 ILLUSTRATED PARTS LIST PAGE 47
Truck Mounted Passenger Stair TMPS-200 Manual No. 307559
Fig.-
Item
NMC-
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
16- Solenoid Installation Ref
307371 Solenoid Assembly (Inc Items 1-9) Ref
303793 Module, Solenoid Control 2
1 303792 Solenoid, 12V, 3 Wire 1
2 303931 Clevis, 1/4-20 x 1/4 Pin 2
3 307365 Shim, Sol. Mnt, 3/8" 1
4 307366 Shim, Sol. Mnt, 3/16" 1
5 307367 Shim, Sol. Mnt, 1/8" 2
6 307368 Shim, Sol. Mnt, 16 GA 2
7 F009704 Washer, Flat, .25 9
8 F018975 HHCS, .25-20x1.25 4
9 F0135881 Nut, Hex, .25 4
10 Comm RHMS, 10-32 x 1.00 1
11 307364 Bracket 1
12 3.0042 Eyebolt 1
13 Comm Washer, 1/4" AN 2
14 Comm Washer, ½" SAE 1
15 Comm HHCS, 1/4-20 X 0.75 6
16 Comm Locknut, 1/4-20 6
17 1.0761 LC098K7 Spring, Compression, 7/8" O.D. X .105
Wire X 3-1/8" Free
1
18 Comm RHMS, 10-32 x 0.75 1
19 1.4474 125-001 Yoke, Brake, 3/16 X #10-32 1
20 Comm Locknut, #10-32 NF 2
