CHAPTER 4 REPAIR PARTS MARCH 31, 2008
4 ILLUSTRATED PARTS LIST PAGE 53
Truck Mounted Passenger Stair TMPS-200 Manual No. 307559
Fig.-
Item
NMC-
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
19- 8807 Beacon, Rotating, Option Ref
1 2.3911 Amber
RB11-12V
Rotating Light (10402) 1
2 2.1532 Wire, 14 Ga. 192”
3 2.1031 8801-K22 Toggle Switch, Beacon On-Off (15605) 1
4 562A518 Placard, Beacon On/Off 1
Fig
Item
NMC-
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
19- 306992 Cab Rotating Beacon, Option Ref
1 306993 Beacon, Rotating, Amber 1
2 2.1532 Wire, 14AWG Type GPT Black 192”
3 2.1031 Switch, Toggle, Spnd 1
4 562A518 Placard, Beacon 1
Fig.-
Item
NMC-
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
19- 305259 Beacon, Flashing, Amber, Option Ref
1 305260 Light, Beacon, Flashing, Amber 1
2 2.1532 Wire 14GA Black (30 inches each) 2
3 2.1031 Switch, Toggle 1
4 562A518 Placard, Beacon, On/Off 1
Fig.-
Item
NMC-
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
19- 308425 Beacon, Amber, Rot, Dual, Option Ref
1 308426 Light, Beacon, Rot, Amber, Dual 1
2 F006612 Wire 14GA Black GXL 192”
3 2.1031 Switch, Toggle 1
4 562A518 Placard, Beacon, On/Off 1
To Next Page
