NMC-WOLLARD TMPS-200 - Page 179

CHAPTER 4 REPAIR PARTS MARCH 31, 2008
4 ILLUSTRATED PARTS LIST PAGE 61
Truck Mounted Passenger Stair TMPS-200 Manual No. 307559
Fig.-
Item
NMC-
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
23- 306294 315829 Morse Control Shifter Assembly Ref
1 043698 Shaft 1
2 Comm 043716 Nut 2
3 044654 Reflector Strip 2
4 048449 Decal, Patent 1
5 060058 Decal, Morse 1
7 043197 Trunnion 1
6 068444 Knob 1
8 300207-001 Position Strip 1
9 043684 Bracket, Switch 1
10 044406 Light Pipe 1
11 048353 Arm, Switch Actuator 1
12 043685 Support, Cable 1
13 315828 Gate Plate 1
14 045184 Switch 1
16 068703-001 Lever, Shift 1
15 043683-001 Adapter Plate 1
17 044405-001 Housing 1
18 Comm 050151-289 SCR. Phillips Truss Hd. #6-32 x .438 2
19 Comm 050152-274 SCR.Phillips Truss Hd. #10-24 x .313 4
20 050407-033 HHCS .25-28UNF x .50 4
21 050407-842 HHCS .375-24 x .75 2
22 050602-528 Set Scr. Hex Soc. .25-20 x .375 2
23 050803-099 Washer, Int. Tooth, .375 2
24 050908-296 Elestic Stop Nut #10-32 UNF 2
25 050908-336 Elestic Stop Nut .313-24 UNF 1
26 051200-24 O-Ring .188 ID x .313 OD x .063
Wide
2
27 051700-008 Lubricant AR
28 045063-001 Pigtail Assembly 1
29 051800-001 Bulb, G.E. #53 1
30 050801-327 Lockwasher, Split .25 4
