CHAPTER 4 REPAIR PARTS MARCH 31, 2008
4 ILLUSTRATED PARTS LIST PAGE 73
Truck Mounted Passenger Stair TMPS-200 Manual No. 307559
Fig.-
Item
NMC-
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
29- 300865 Canopy Assembly Option Ref
1 301211.1 Pin, Offset Roof, LH 1
301211.2 Pin, Offset Roof, RH 1
2 301187 Roof, Deck 1
3 301268 Overhang, Upper 4
4 301063 Post, Front Deck 2
5 301064 Post, Middle Deck 2
6 301065 Post, Rear Deck 2
7 301210 Strap, Deck Post 2
8 301174 Post, Canopy, Upper Section 6
9 301185 Roof, Upper Section 1
10 310269 Overhang, Lower 1
11 301182 Roof, Lower Section 1
12 301173 Post, Lower Section 8
13 301204.1 Bracket, Deck Post Support, LH 1
301204.2 Bracket, Deck Post Support, RH 1
14 300988 Pin, Roof 18
15 301201.1 Bracket, Lower Section, RH 3
301201.2 Bracket, Lower Section, LH 3
15a 301474.1 Bracket, Lower Section, Bottom, RH 1
301474.2 Bracket, Lower Section, Bottom, LH 1
16 301158 Pin, Straight 6
17 301188 Bracket, Upper Section 6
18 Comm HHCS, 3/8-16 x 0.75, Gr. 5 250
19 Comm Washer, Flat, 3/8 250
To Next Page
