CHAPTER 4 REPAIR PARTS MARCH 31, 2008
4 ILLUSTRATED PARTS LIST PAGE 77
Truck Mounted Passenger Stair TMPS-200 Manual No. 307559
Fig.-
Item
NMC-
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
31- 306247 Step Reinforcement Option Ref
1 302847.1 Side Support Angle (LH) 21
2 302847.2 Side Support Angle (RH) 21
3 302848.1 Adjustable Step Support 9
4 302848.2 Main Step Support 13
5 302848.3 Flip/Intermediate Step Support 2
NS 3.3241 Rivet 1500
