CHAPTER 4 REPAIR PARTS MARCH 31, 2008
4 ILLUSTRATED PARTS LIST PAGE 93
Truck Mounted Passenger Stair TMPS-200 Manual No. 307559
Fig.-
Item
NMC-
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
36- 307619 Shut Down, Low Oil, TMPS200 Gas/Dsl,
Opt (SN1381+)
Ref
1 Ford Pressure Switch Ref
2 3.2283 Ftg, Hyd, 04MP-02FP 3
3 2.3707 Pressure Switch, SP2C-8F-8PSI 1
4 F002958 Wire, Bk, 16Ga 240”
5 2.3478 Conduit, Flexgaurd, 1/4” 120”
6 NW035374 Switch, On-Off, Momentary 1
7 3.0802 Ftg, Hyd, Tee, 04MP-04MP-04MP 1
8 NW035382 Insert, Blank 1
9 37408 Connector, Switch 1
10 562A347 Placard, Low Oil Bypass (Not Shown) 1
11 14762.8 Hose Assy, #04M, 26” LG, ST/90 1
12 3.1352 Ftg, Hyd, 04MJ-02MP 2
