CHAPTER 4 REPAIR PARTS SEPTEMBER 30, 2008
4 ILLUSTRATED PARTS LIST PAGE 115
Truck Mounted Passenger Stair TMPS-200 Manual No. 307559
Fig.-
Item
NMC-
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
45- 308707 Truck Prep, F350 V8 Gas, 5.4L H 1
1 306307 Truck Chassis, F350V8 Triton Gas 1
2 307298 Glass, 1/4x16x16x2.5RD 1
3 303769 HHCS 3/8-16x1.5 Gr8 8
4 308703 Pump Kit w/Clutch, V8, Gas (see fig 46) 1
5 308827 Retainer, Spacer Plt, 200 2
6 308870 Spacer, Front Axle, Top, 200 1
7 308826 Spacer Wld, Frt Axle, LH Top, 200 1
8 304427 Trim w/Seal, .25x.75 OD, 90 Deg 70”
9 307372 Seal, Windshield 70”
10 8797.94 Hose Asm, #8M 1
11 308882.1 Hose Asm , #16L 1
12 90413 Ftg, Hyd, 08MJ-08MB
13 203852 Ftg, Hyd, 12MJ-10MB 1
14 303742 Brkt, Tail Light RH 1
15 303773 Brkt, Tail Light LH 1
17 NW036922 HHCS, 3/8-16x6.5 Gr5 6
18 RF090896 Sleeve, Alum Fbrgls 2.50 240”
NS 562A279 Decal, Gasoline Only 1
To Next Page
