CHAPTER 4 REPAIR PARTS SEPTEMBER 30, 2008
4 ILLUSTRATED PARTS LIST PAGE 117
Truck Mounted Passenger Stair TMPS-200 Manual No. 307559
Fig. -
Item
NMC-
Wollard
Part No.
Vendor
Part No.
Nomenclature Eff Units
Per
Assy
46- 308703 Pump Kit w/Clutch F350 V8, Gas, 2008+ H
1 308970 711677 Pump Bracket 1
2 308971 711072 Idler Bushing 1
3 308972 Pump (rear port) 1
4 308973 740162 Clutch 1
5 308974 740389 Idler Pulley 1
6 Stud Bolt 1
7 110140 M8 X 1.25 x 60 Bolt 1
8 110479 M10 x 1.5 x 30 Bolt 1
9 110465 3/8 x 1-1/4 Socket Head Bolt 2
10 110271 3/8 Lock Washer, .55 O.D. X .13 Thick 2
11 110703 M8 Flat Washer 1
12 Idler Pulley 1
13 Nut 1
14 Wire 1
15 308975 740357 Belt, Gates 6K126.68 1
16 308976 740339 Idler Pulley 1
17 308977 711688 Idler Bushing 1
18 110488 M10 x 1.5 x 45 Bolt 1
19 110676 3/8 Flat Washer 1
To Next Page
