NOTE: All hydraulic stair functions are manually activated by switches in the cab
which control hydraulic solenoid valves.
IMPORTANT: The sta bi liz ers are in ter locked to pre vent mov ing the unit if the
sta bi liz ers are in the down po si tion. The engine will shut down if shifted out of park or
neutral.
There is a flashing "STABILIZER NOT RETRACTED" indicator lamp to alert
the operator movement can not be attempted until they are retracted.
NOTICE! When the “STABILIZERS NOT RETRACTED” indicator is ON, the stabilizers
are not fully retracted and the stair can not be driven.
Shifter - optional floor mounted shifter with P-R-N-D to shift transmission. See
figure 2.
Always apply park brake when shifted to neutral (N). Unintended
movement could result in persons falling or being crushed.
CHAPTER 1 GENERAL INFORMATION & OPERATION INSTRUCTIONS JANUARY 31, 2014
2 OPERATION PAGE 3
Truck Mounted Passenger Stair TMPS-200 Manual No. 307559
FIGURE 2. OPTIONAL FLOOR
MOUNTED SHIFTER
