CONNECTING THE PROPELLER SHAFT
Measure the minimum distance
(A)
between the notch
of
the tractor
PTO
and
that
of
the shredder, when they
are
on
the
B
=
A-
1"
Measure the distance of the propeller shaft, in the position of minimum
extension (all
The measureB should be smaller thanA of at least
1
inches.
During work both inside that outside plastic pipes should not bump
against heads.
If the propeller shaft is too long,
before cutting
metal pipes and guards,
it is necessary to check that, when it
is
in the maximum extension
position, inside metal pipes remain overlapped at least of
1/3
of the
length
(L).
If
the overlappingis smaller, there is too much difference between
the minimum and maximum position
of
the transmission.
If
this occurs,
it
is necessary to ask for. longer lower connecting
arm to space more the machine from the tractor.
Be careful
to
cut
surface: trim the
cut
inside and outside, clean
for eliminating chips and dirt, and grease with lithium grease.
Always check that the shaft is dimensioned according
to
the
power
of
the machine declared.
Check that the propeller shaft does not take angles over the value
admitted.
Check that the machine cannot be raised over the maximum
dimension allowed by the shaft length:
it
could come out.
Max
20"
MAXIMUM
20"
working
still
