ACCESSORY WEARING METAL SHEET
METAL SHEET ASSEMBLY Remove the lower counterblade.
On machine: BNG
230 e BNG 270 with internal metal sheet ONLY counterblades
low profile.
Position the metal sheet
and the specified counterblade.
Usually nuts are fitted at the external side.
Fit
the upper row of fastening bolts by drilling the sheet if necessary
(holes
: 10 mm) .
STOP TRACTOR ENGINE
DISCONNECT TRACTOR
P.T.O.
TAKE THE KEY OFF THE DASHBOARD
MAKE
SURE ALL MOVING PARTS ARE IDLE
FRAME
METAL SHEET
COUNTERBLADE
FOR METALSHEET
BNG 230 40
x 10 L= 2290 mm
Cod: 1681128
COUNTERBLADE
FOR METAL SHEET
BNG 270
Cod: 1421049
BNG 310
Cod: 1681101
. Cod: 1561103.
40
x 18 L = 2635 mm
40
x 20 L= 1070 mm? 40x20 L=1920
(NO CHANGE )
a
SO AS TO MAKE SURE THAT BLADES DO NO TOUCH THE FRAME
...
. .
