BELT TENSION
A
B'
I
Load
Arrow
(F
Loosen bolts
(
A,
no.
4
)
and
(
B,
no.
1
)
which fasten transmission to shredder frame.
Loosen adjustingscrew counternuts
(
H
and
D
).
Turn
adjusting screw
(
E
)
clockwise, and turn screw
(
G
),
anticlockwise, up to get the tension
desired (See the table).
That operation allows transmission axis
(
PR
)
to be parallel
to
rotor axis.
Tighten
bolts
(
A
and
B
)
and counternuts
(
D
and
H
).
In
order to check parallelism between transmission
axis
and rotor
axis,
follow the indications
listed below:
IF THE MACHINE
IS
COUPLED
TO
THE
TRACTOR,
THE
CARDAN
TRANSMISSION
Dismount the
belt
safety guard.
Put
a scale on the edges of the rotor pulley and rotate it
until
it touches
the
edges
of
the other pulley.
Both pulley edges shall touch the scale;otherwise, screw or unscrew adjustingscrew
(G
)
accordingly,
after loosening screws
(
A
and
B
).
Shredders model
BNG
are equipped with belts type
SPBX
:
tension
of
such
belts
must
be
restored within the first
3
working hours.
Afterwards,check belt tension periodically.
If
rotor rotation speed decreases and belt tension can not
be
restored correctly,
change belts.
I
C
E
