WORKING HEIGHT ADJUSTMENT
/
-
BLADES
MUST
NEVER
TOUCH
THE
GROUND
LEAVE
AT
LEAST
1.5
"
\.
ROLLER VERSION:
LIFT
THE
MACHINE
FROM
THE
GROUND
Loose bolts
(AS
)
on a side, remove bolts
(
AD
)
on the other side.
On the support select the holes right for the desired height, then
fit
bolts
(
AD
)
and screw nuts do not tighten
them.
Remove
bolts
(
AS
),
and
fit
them into the holes corresponding to those selected on the other side.
Screw and tighten all bolds..
NG
230 270 270B
310
BNG
270
F
AS
WHEELS
VERSION
LIFT
MACHINE
FROM
THE
GROUND
Loosen bolt
(
C
),
remove bolt
(
D
)
.
On the support select the holes right for the
desired height, then
fit
bolt
(
D
).
Tighten all nuts.
Perform the same operation on the other wheels.
TO
AD
JUST
WHEEL
TRACK:
Loosen
bolts
(
B
),
make the
wheel
block slide
until
it
reaches the position required, then
tighten
bolts
(
B
).
LIFT
THE
MACHINE
FROM
THE
GROUND
