PARTS LIST
LISTA DE PIEZAS
Speed Scrubt 2001 Battery (11–01)
37
SOLUTION TANK GROUP
GRUPE DEL DEPÓSITO DE DISOLUCIÓN
REF PART # DESCRIPTION QTY.
∇ 608518 ASM, COVER SOL. TANK GREEN 1
Y 1 608284 COVER, SOLUTION TANK GREEN 1
Y 2 611068 HINGE, COVER 1
Y 3 140706 RIVET, POP 1/8 7
4 608627 TANK, SOLUTION GREEN 1
5 607099 DSCREEN, SOLUTION FILL 1
6 3701.6 SCREW, #6X3/8 2
7 140032 WASHER, #6 FLAT 2
8 230665 BRACKET, CHARGER PLUG 1
9 140018 WASHER, #10 INT 2
10 140951 SCREW, 10–24X7/16 2
11 140831 SCREW, 6–32X5/8 2
12 140019 WASHER, #6 EXT 2
13 605387 DCONNECTOR, RED 50A 1
14 230925 SUPPORT, RECOVERY TANK 1
15 611418 BUSHING 1
16 140027 WASHER, 5/16 FLAT 2
17 140015 WASHER, 5/16 SPLITLOCK 1
18 140226 SCREW, 5/16–18X5/8 1
19 621324 DPLUG, EXPANSION 1–1/2”DIA 1
20 140011 WASHER, 3/16 FLAT 1
21 140350 SCREW, #10X1/2 1
22 600476 DSTRAP, PLUG REAR FILL 1
∇ ASSEMBLY / CONJUNTO
Y INCLUDED IN ASSEMBLY / INCLUIDO EN EL CONJUNTO
D RECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS
REF PART # DESCRIPTION QTY.
23 14884 FITTING, 3/8MX1/2H BARB BRS 2
24 700420 ASM., HOSE W/SOL. INDICATOR 1
25 607776 CLAMP, HOSE 2WIRE BLK 1
26 608455 DECAL, SPEED SCRUB 2001 SIDE 2
27 608185 DECAL, NOBLES 6.75” LOGO 1
28 150419 FITTING, 1/4MX3/8H ELB 90 2
29 607775 CLAMP, HOSE 2WIRE BLK 2
30 606240 DHOSE, 3/8IDX5/8ODX10.25 1
31 605324 GASKET, 1/2” CLOSED CELL 2
32 602927 TRAY, BATTERY 1
33 120589 DECAL, BATTERY PLACEMENT 1
34 602592 SUPPORT, TUBE BATTERY 1
35 130364 DCABLE, BATTERY #6BLKX15” 1
36 140835 SCREW, 10–24X3/8 2
37 230311.BK SHIELD, LIGHT 1
38 130023 LIGHT, SAFETY 24VDC 14” 1
39 130869 BATTERY, 12V 130AH (WET) 2
600594 BATTERY, 12V 130AH (DAMP) 2
40 603553 CHARGER, 24DC/12A 120V 1
130859 CHARGER, 24V 15AMP 230V/50HZ 1
41 700169 WIRE, #12X17 5/16 BLK 1
42 700168 WIRE, #12X12 3/8 RED 1
