OPERATION
8
Speed Scrubt 2001 Battery (11–01)
MACHINE OPERATION
FOR SAFETY: Do not operate machine unless
operator manual is read and understood.
1. Adjust control grips to a comfortable operating
height (three settings). Squeeze together two
levers under console to raise or lower control grips
(Figure 10).
FIG. 10
2. Lower squeegee by releasing squeegee lift lever
from the lock position (Figure 11).
FIG. 11
3. Lower brush head, step down firmly on top brush
lift pedal and push pedal forward to lower
(Figure 12).
FIG. 12
4. Turn vacuum switch to the on position.
5. Push solution flow lever forward to desired flow
rate. Solution will immediately begin to flow once
lever is activated (Figure 13).
FIG. 13
To adjust the maximum solution flow rate, turn
solution flow adjustment knob down to increase or
up to decrease (Figure 14).
FIG. 14
