PARTS LIST
LISTA DE PIEZAS
Speed Scrubt 2001 Battery (11–01)
39
SOLUTION TANK REAR PANEL GROUP
CONJUNTO PANEL TRASERA
REF PART # DESCRIPTION QTY.
1 100151 DGASKET, TUBE–ADAPTER 1
2 230664 ADAPTER, TUBE 1
3 140424 SPRING, TUBE–ADAPTER 1
4 230873 MOUNT, PLATE WELDMENT 1
5 160617 DHOSE, VAC 1–1/2X24” W/CUFFS 1
6 230927 PLATE, VALVE STOP 1
7 140027 WASHER, 5/16 FLAT 3
8 140015 WASHER, 5/16 SPLITLOCK 4
D RECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS
REF PART # DESCRIPTION QTY.
9 140226 SCREW, 5/16–18X5/8 4
10 140548 NUT, 5/16 FINJAM 2
11 240191 KNOB, 5/16–18X2” 1
12 140259 SCREW, 1/4–20X5/8 2
13 140016 WASHER, 1/4 LOCK 2
14 140000 WASHER, 1/4 FLAT 2
15 230872 LATCH, PLATE BRUSH LIFT 1
