PARTS LIST
LISTA DE PIEZAS
Speed Scrubt 2001 Battery (11–01)
41
RECOVERY TANK GROUP
CONJUNTO DESPÓSITO RECUPERAR
REF PART # DESCRIPTION QTY.
∇ 1 701103 ASM, STANDPIPE W/NIPPLE 1
Y 2 606088 FITTING, 1–1/2” NIPPLE 1
3 101714 DGASKET, WASTE AIR CHAMBER 1
4 210240 NUT, 1–1/2 FPT FLNG METAL 1
5 180613 DFLOAT, SHUT–OFF (1) BALL 1
6 608629 TANK, RECOVERY GREEN 1
∇ 7 100102 DASM., LID CLEAR W/STND HOLE 1
Y 8 100105 DLID, CLEAR CENTER ONLY 1
Y 9 100109 DLID, OUTER RING ONLY 1
10 140826 SCREW, #6X3/4 6
11 630420 DECAL, ”FLAMMABLE MATERIAL” 1
12 578729 DECAL, READ MANUAL 1
13 3701.6 SCREW, #6X3/8 2
14 230513 CHAIN 1
15 621324 DPLUG, EXPANSION 1–1/2”DIA 1
16 578441 DSTRAP, DRAIN HOSE 1
17 630394 DSLEEVE, DRAIN HOSE 1
18 605558 DHOSE, DRAIN 1
19 607777 CLAMP, HOSE 1WIRE BLK 1
∇ ASSEMBLY / CONJUNTO
Y INCLUDED IN ASSEMBLY / INCLUIDO EN EL CONJUNTO
D RECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS
REF PART # DESCRIPTION QTY.
20 140259 SCREW, 1/4–20X5/8 2
21 140016 WASHER, 1/4 LOCK 2
22 140000 WASHER, 1/4 FLAT 2
23 140960 DCABLE, REC. TANK SUPPORT 1
24 120588 DECAL, BATTERY RECHARGING 1
25 606923 STUD, 1/4–20X4.25 3
26 100038 DGASKET VAC MOTOR 1
∇ 27 605357 DMOTOR, VAC 24V 1/2 HP 1
Y 190163 DBRUSH, CARBON 2/PK 2
28 130133 TERMINAL, MALE .25 2
29 600009 DMUFFLER, VAC EXHAUST 1
30 130041 WIRE TIE, 11–1/2X.19 1
31 140501 NUT, 1/4–20 NYLOCK 3
32 140000 WASHER, 1/4 FLAT 3
33 605244 DHINGE, RECOVERY TANK 1
34 140000 WASHER, 1/4 FLAT 9
35 140052 WASHER, 1/4 EXT 9
36 140885 SCREW 1/4–20X1/2 9
37 140300 CLAMP, INSULATED 1/2”ID 1
