PARTS LIST
LISTA DE PIEZAS
Speed Scrubt 2001 Battery (11–01)
43
CONTROL CONSOLE GROUP
CONJUNTO CONSOLA DE CONTROLES
REF PART # DESCRIPTION QTY.
1 200823 GRIP, HANDLE TUBE 2
2 608605 DSWITCH, ROCKER DPST SEAL 2
3 606020 DMETER, BATTERY VOLTAGE 24V 1
4 600641 DECAL, DASH 1
5 608625 CONTROL CONSOLE GREEN 1
6 230709 HANDLE, TUBE 1
7 230744 BRACKET, ELECTRONICS MOUNT 1
8 100058 TAPE, ACRYLIC FOAM – 1” 1
9 130021 DFLASHER, 24VDC 1
10 130756 DBREAKER, CIRCUIT 35A 1
11 610949 COVER, CONTROL CONSOLE 1
12 140018 WASHER, #10 INT 2
13 140197 SCREW, 10–24X3/8 2
14 606105 DECAL, DO NOT SPRAY 1
15 120649 DECAL, WARNING BATT. MCHNS 1
16 281001009 DTERMINAL, RING #10 2
D RECOMMENDED STOCK ITEMS / ARTICULOS RECOMENDADOS
REF PART # DESCRIPTION QTY.
17 606404 DASM., DIODE W/RING TRMNLS 1
18 140519 NUT, 10–24 KEP 2
19 130218 DSOLENOID, 24 VDC 1
20 140900 SCREW, 10–24X3/4 1
21 140916 CLAMP, CABLE 5/8ID 1
22 230715 TUBE, HANDLE ADJUSTMENT 1
23 230649 PIN, HANDLE ADJUSTMENT 2
24 230710 PIN, HANDLE LOCK 2
25 140415 SPRING, LOCK PIN 1
26 140241 BOLT, SHOULDER 5/8 X 2 2
27 700167 HARNESS, WIRE MAIN 1
28 140900 SCREW, 10–24X1 2
29 140307 CLAMP HOSE 3/4 TO 1–3/4 2
30 140018 WASHER, INT. 2
31 605823 DO–RING .926 ID X .99600 2
32 609969 DPLUG, HOUR METER 2
To Next Page
